Wankel aircraft-engine




Description:       - single or twin rotor rotary piston engine
- liquid cooled housing
- charge-cooled rotor
- roller-bearing
- "tric-injection" fuel injection system
- engine management system
- dual electronic ignition
- generator
- electric starter
- cogbelt reduction drive

Aircraft-engine LCR - 407 SGti


Modell  LCR - 407 SGti
Design single rotor injected engine
Dim. [mm] L x W x H
                 l x w x  h
481 x 462 x 430
404 x 280 x 285
Weight [kg] Engine
                   Drive
                   Elektric system
25,0
6,5
3,5
Performance [kW(hp)]
at speed [rpm]
27 (37)
6000
Torque [Nm]
at speed [rpm]
42
4500
Displacement [cm³] 407
BCFC [g/kWh] 300
Fuel unleaded gasoline / Mogas (ROZ 92) or 1:80-mixture (premix)
Lubrication standart-2-stroke-oil (API-TC)
Ignition unit WANKEL tric-injection with engine management system
electric starter 12 V / 900 W
Generator 14 V / 200 W
Standard specifikation Engine equipment with electric starter, generator, airfilter, engine management system with twin spark ignition
Optional nirosta exhaust muffler, radiator, 3:1 HDT cogbelt reduction drive

Aircraft engine LCR - 814 TGti


Modell LCR - 814 TGti
Design twin rotor injected engine
Dim. [mm] L x W x H
                 l x w x  h
600 x 462 x 430
523 x 280 x 285
Weight [kg] Engine
                   Drive
                   Elektric system
35,0
6,5
4,5
Performance [kW(hp)]
at speed [rpm]
55 (75)
6000
Torque [Nm]
at speed [rpm]
90
4000
Displacement [cm³] 814
BCFC [g/kWh] 300
Fuel unleaded gasoline / Mogas (ROZ 92) or 1:80-mixture (premix)
Lubrication standart-2-stroke-oil (API-TC)
Ignition unit WANKEL tric-injection with engine management system
electric starter 12 V / 900 W
Generator 14 V / 200 W

Standard specifikation Engine equipment with electric starter, generator, airfilter, engine management system with twin spark ignition
Optional nirosta exhaust muffler, radiator, 3:1 HDT cogbelt reduction drive
